This document describes ZBT-WE5931-T’s electrical characteristics, RF performance, size, application environment and so on. From this document, end users or developers can quickly understand the hardware functions of this router. .
ZBT-WE5931-T is a 4G routing product for home used. It accesses the Internet through 4G mobile communication dial-up or 100Mbps WAN port dial-up, and then shares the wireless WiFi and internet network to user or device.
And also,it can be supported wired Ethernet .Customers can be connected WAN port by wired Ethernet cable to share wireless WiFi and wired network to user or device.
HARDWARE FEATURES |
CPU | MT7628DAN |
Interface | 1 * 10/100 Mbps WAN Port
3 *10/100 Mbps LAN Ports 1 * SIM Card Slot |
Button | Reset Button |
External Power Supply | Power Adapter: Input Power 100-240v~50/60 Hz 0.6A
Output parameter 12VDC 1A |
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
Antenna | 2*Detachable 4G Antennas, 2*non-detachable WiFi antennas |
WIRELESS FEATURES |
Wireless Standards | IEEE 802.11n.IEEE 802.11g.IEEE 802.11b.IEEE 802.3u |
Frequency | 2.4 GHz |
Wireless Rate | MAX 300Mbps |
Wi-Fi Max.Associated Clients | 30 |
WAN Failover | Yes |
Wireless Security | WPA/WPA2, WPA-PSK |
SOFTWARE FEATURES |
WAN Type | PPPoE.Dynamic IP. Static IP |
Port Forwareding | Support |
Static Router | Support |
System Log | Support |
Parent control | Support |
SSID Hidden | Support |
Black list | Support |
Cloud management | Support |
NTP | Support |
DHCP | Support |
VPN | Support |
Elevate Your Connectivity with the WE5931-T 580MHz 300Mbps WiFi 4G Router
Superior Performance, Unmatched Connectivity
Experience the pinnacle of connectivity with the WE5931-T 580MHz 300Mbps WiFi 4G Router. Engineered with precision and powered by the latest Mediatek MT7628DAN wireless solution, this router delivers unparalleled performance and functionality. Enjoy stable wireless performance at 2.4GHz with blazing-fast speeds of up to 300Mbps, ensuring seamless streaming, gaming, and browsing experiences. Plus, with support for 3G&4G connectivity (3G&4G PCIE mode required), stay connected wherever you go.
Robust Hardware, Seamless Integration
Designed for reliability and convenience, the WE5931-T features robust hardware components that ensure smooth operation and seamless integration into your home or office network. Equipped with a powerful MT7620N CPU and versatile interfaces including one 10/100 Mbps WAN Port, two 10/100 Mbps LAN Ports, and a SIM Card Slot, this router offers flexible connectivity options to meet your specific needs. With detachable 4G antennas and non-detachable WiFi antennas, enjoy extended coverage and superior signal strength throughout your space.
Advanced Software Features for Ultimate Control
Take command of your network with the advanced software features of the WE5931-T 580MHz 300Mbps WiFi 4G Router. From PPPoE and Dynamic IP support to port forwarding and VPN capabilities, customize your network settings effortlessly to suit your preferences. Benefit from features like parental control, SSID hiding, and blacklisting to ensure a safe and secure online environment for you and your family. Plus, with cloud management and NTP support, manage your network with ease from anywhere, anytime.
